12kv Epoxy Resin High Voltage Insulator Cabinet Contact Box SO5-12-250

The contactor box is an electrical connection device widely used in high-voltage circuits. It consists of a main body box, terminals, contacts, etc., which can effectively connect the power supply to the electrical equipment.
The contactor box has a wide range of uses and is widely used in various industries such as lighting, electrical appliances, machinery, communications, and transportation. It is especially suitable for occasions where multiple electrical connections with multiple devices are required.

1. Rated voltage: 12kV;
2. Model: SO5-12-250;
3. Withstand short-time (4 seconds) opening current: 25kA;
4. Withstand short-time (4 seconds) closing current: 63kA;
5. Rated frequency: 50/60Hz;
6. Protection level: IP65;
7. Number of operations: 2000 times;
8. Temperature range: -40℃~+70℃;
9. Weight: about 4.2kg.
