Brief Introduction Of High Magnetic Resistance Energy-saving Bolt Tension Clamp

To understand the high magnetic resistance energy-saving bolt tension clamp, first understand its function. The function of the high magnetic resistance energy-saving bolt tension clamp: to solve the problems of low grip, easy relaxation and wear of ordinary wire clamps in power transmission lines; including: wire clamp body, wire pressing plate, U-shaped bolt;

Cutout fuse Features:

There is a long duckbill U-shaped groove at one end of the wire clamp body, and the end is in the shape of a trumpet. 2 to 5 equidistant U-shaped bolt seats are set corresponding to the edge of the duckbill U-shaped groove. There is a curved part at the rear end of the duckbill U-shaped groove, and the top of the protrusion has a bolt hole. A shorter U-shaped groove is set at the other end of the curved part, and the end is a fan-shaped trumpet;

There are 2 to 5 wire pressing plates, with a hump protrusion on the top, a hump groove between the protrusions that matches the curved part of the U-shaped bolt, and an arc-shaped groove that matches the conductor at the bottom, and a left-handed convex pattern in the groove;

The wire pressing plate is die-casted from high magnetic resistance material with a smooth outer contour;

There are 2 to 5 U-shaped bolts. The wire pressing plate is placed in the long duckbill-shaped U-shaped groove so that the U-shaped groove on its top corresponds to the U-shaped bolt seats on both sides of the duckbill. The U-shaped bolt is inserted into the U-shaped groove on the top of the cover plate and passes through the bolt seat, and the nut is tightened.
